stm32EPC8266連接心知天氣網源程序

ID:190564 · 發表于 2021-7-2 10:17

stm32天氣預報基本功能，連接上心知天氣網，并解釋cJSON格式數據，可以再TFTlcd屏幕顯示

單片機源程序如下:

#include "config.h"
Results results[] = {{0}}; //存儲json數據的結構體
u8 get_current_weather(char *JSON, Results *results);
int main()
{
//初始化變量
u8 i = 0;
u8 DTH11_Refresh = 0;
u8 len, t, j, k;
u8 key = 0;
u8 duoji = 100;
u32 sd_size;
u8 sd_buf[6];
u32 free,total, sdCapacity;
u8 Read_ok_flag = 0;
FIL file; //文件對象
FATFS fatfs; //邏輯驅動器的工作區
static FRESULT res; //FRESULT函數公共結果代碼
char write_buffer[1024]; //寫文件緩沖區
char read_buffer[1024]; //讀文件緩沖區
UINT counter;
uint8_t json_buff[512];//接受json數據的緩存數組
//char message[1024] = "{ \"results\":[{\"location\":{\"id\":\"wwww4d\",\"name\":\"beijng\",\"country\":\"CN\",\"path\":\"bejing,shanghai,guangzhou\",\"timezone\": \"Asia/Shanghai\",\"timezone_offset\": \"+08:00\"},\"now\":{\"text\":\"12\",\"code\": \"9\",\"temperature\": \"17\"},\"last_update\": \"2021-05-31T10:45:00+08:00\"}]}";
/*-------------------------------------------------------------------------------------------------------------------------------------------------*/
/*-------------------------------------------------------------------------------------------------------------------------------------------------*/
//外設初始化
SysTick_Init(72); //節拍定時器頻率設置 72M
NVIC_PriorityGroupConfig(NVIC_PriorityGroup_2); //設置NVIC中斷分組2:2位搶占優先級，2位響應優先級，用于串口助手有數據發送時的中斷
USATR1_Init(115200); //串口1初始化為115200
USART3_Init(9600); //串口3 樹莓派通信 / 語音模塊
TIM3_Init(2000-1, 720-1); //周期是20ms PWM輸出
TIM4_Init(6000-1,36000-1); //定時3s
LED_Init(); //LED燈初始化
TFTLCD_Init(); //TFTLCD屏幕初始化
KEY_Init(); //按鍵初始化
ESP8266_Init(115200); //ESP8266初始化，里面包含串口2的初始化
RF433M_Init(); //433M射頻模塊
EN25QXX_Init(); //初始化falsh
my_mem_init(SRAMIN); //初始化內部內存池
FATFS_Init(); //為fatfs相關變量申請內存沒有這個申請內存，fatfs文件系統就不能用
RTC_Init(); //RTC時鐘
/*-------------------------------------------------------------------------------------------------------------------------------------------------*/
/*-------------------------------------------------------------------------------------------------------------------------------------------------*/
FRONT_COLOR=BLACK;//設置字體為黑色 12號字體，X軸可以0-220 Y軸可以0-380
LCD_ShowFont12Char(60,0,"智能家居控制");
LCD_DrawLine(0, 16, 240, 16); //畫線
LCD_DrawLine(0, 17, 240, 17);
LCD_DrawLine(0, 130, 240, 130); //畫線
LCD_DrawLine(0, 131, 240, 131);
LCD_DrawLine(105, 16,105, 130); //豎線
FRONT_COLOR=RED; //設置字體為紅色，打印出錯時的字體
//SD卡
while(SD_Init()!=0)
{
LCD_ShowFont12Char(10,30,"SD Card Error!");
}
f_mount(fs[0],"0:",1); //掛載SD卡外設 如果為1那么就會強制的進行加載操作
f_mount(fs[1],"1:",1); //掛載FLASH. 外設
//FATF文件系統
while(FATFS_GetFree("0", &sdCapacity, &free) != 0)
{
LCD_ShowFont12Char(10, 50, "SD Card FAT ERROR!");
}
// //溫濕度模塊
// while(DHT11_Init())
// {
// LCD_ShowString(130,150,tftlcd_data.width,tftlcd_data.height,16,"DHT11 Error ");
// delay_ms(500);
// }
FRONT_COLOR=BLACK; //恢復字體為黑色
/*-------------------------------------------------------------------------------------------------------------------------------------------------*/
/*-------------------------------------------------------------------------------------------------------------------------------------------------*/
//溫濕度模塊數據顯示
LCD_DrawLine(0, 378, 240, 378); //畫線
LCD_DrawLine(0, 379, 240, 379);
LCD_ShowString(0,380,tftlcd_data.width,tftlcd_data.height,16,"Temp: C");
LCD_ShowString(100,380,tftlcd_data.width,tftlcd_data.height,16,"Humi: %RH");
LCD_ShowFont12Char(110,20,"城市:");
LCD_ShowFont12Char(110,60,"天氣:");
LCD_ShowFont12Char(110,100,"RTC時鐘:");
ESP8266_STA_TCPClient_Test();//連接熱點＋連接服務器
while(1){
// LCD_Clear_one(WHITE,0,150,240, 150);
get_current_weather((char *)json_buff, results);
Clean_buff1();
printf("qingchuhou\n%s\n",ESP8266_Fram_Record_Struct .Data_RX_BUF);
LCD_ShowString(155,20,175,20,16,results[0].location.name);
LCD_ShowString(155,60,175,60,16,results[0].now.text);
//
if(strcmp(results[0].now.text, "Sunny") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_shower_rain);
else if(strcmp(results[0].now.text, "Fair") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_fair);
else if(strcmp(results[0].now.text, "Cloudy") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_cloudy);
else if(strcmp(results[0].now.text, "Mostly_cloudy") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_mostly_cloudy);
else if(strcmp(results[0].now.text, "partly_cloudy") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_partly_cloudy);
else if(strcmp(results[0].now.text, "moon_cloudy") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_moon_cloudy);
else if(strcmp(results[0].now.text, "overcast") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_overcast);
else if(strcmp(results[0].now.text, "shower_rain") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_shower_rain);
else if(strcmp(results[0].now.text, "thunder_shower") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_thunder_shower);
else if(strcmp(results[0].now.text, "hail") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_hail);
else if(strcmp(results[0].now.text, "light_rain") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_light_rain);
else if(strcmp(results[0].now.text, "moderate_rain") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_moderate_rain);
else if(strcmp(results[0].now.text, "heavy_rain") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_heavy_rain);
else if(strcmp(results[0].now.text, "storm") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_storm);
else if(strcmp(results[0].now.text, "heavy_storm") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_heavy_storm);
else if(strcmp(results[0].now.text, "severe_storm") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_severe_storm);
else if(strcmp(results[0].now.text, "freezing_rain") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_freezing_rain);
else if(strcmp(results[0].now.text, "snow_flurry") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_snow_flurry);
else if(strcmp(results[0].now.text, "light_snow") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_light_snow);
else if(strcmp(results[0].now.text, "moderate_snow") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_moderate_snow);
else if(strcmp(results[0].now.text, "heavy_snow") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_heavy_snow);
else if(strcmp(results[0].now.text, "snow_storm") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_snow_storm);
else if(strcmp(results[0].now.text, "dust") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_dust);
else if(strcmp(results[0].now.text, "sand") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_sand);
else if(strcmp(results[0].now.text, "sand_storm") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_sand_storm);
else if(strcmp(results[0].now.text, "dust_storm") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_dust_storm);
else if(strcmp(results[0].now.text, "foggy") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_foggy);
else if(strcmp(results[0].now.text, "haze") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_haze);
else if(strcmp(results[0].now.text, "windy") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_windy);
else if(strcmp(results[0].now.text, "gale") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_gale);
else if(strcmp(results[0].now.text, "hurricane") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_hurricane);
else if(strcmp(results[0].now.text, "cold") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_cold);
else if(strcmp(results[0].now.text, "hot") == 0) LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_hot);
else{
LCD_Draw_Picture(0,20,100,120,(u8 *)gImage_unknown);
}
}
return 0;
}
//獲取一次實時天氣
//返回：0---獲取成功，1---獲取失敗
u8 get_current_weather(char *JSON, Results *results)
{
while(!ESP8266_UnvarnishSend());//返回1：配置成功 0：配置失敗
//printf("清除前%s\n",ESP8266_Fram_Record_Struct .Data_RX_BUF);
Clean_buff();
//printf("清除后%s\n",ESP8266_Fram_Record_Struct .Data_RX_BUF);
ESP8266_SendString(ENABLE, "GET api.seniverse點com/v3/weather/now.json?key=S1EB-JUvy4icX5_CO&location=Wuxi&language=en&unit=c\r\n", 0, Single_ID_0 );
delay_ms(1000);
strcpy(JSON,(char *)ESP8266_Fram_Record_Struct .Data_RX_BUF);
cJSON_WeatherParse( JSON, results);
//Clean_buff1();
ESP8266_ExitUnvarnishSend(); //退出透傳
//獲取三天的天氣（包括今日）
//ESP8266_SendString(ENABLE, "GET api.seniverse點com/v3/weather/daily.json?key=50alegxkcaehcge6&location=wuxi&language=en&unit=c&start=0&days=5\r\n", 0, Single_ID_0 );
return 0;
}

復制代碼

所有資料51hei提供下載:

smartHouse.7z (451.21 KB, 下載次數: 40)

ID:64089 · 發表于 2021-7-6 16:15

謝謝樓主分享，很好的學習資料
